EcoSmart Fire | Ethanol Burner | ESF.2.B.AB3

EcoSmart Fire AB Series Round Stainless Steel Ethanol Fireplace Burner

Regular price $1,195.00

A round ethanol burner made for bowls, tables and sculptural fire features. A compact, centered flame from a burner you set into your own design.

Need a different shape? See every EcoSmart ethanol burner.

Call to Order

Call or text 1-866-713-2399 to get the best deal!

Free delivery to contiguous U.S. + free 30-day returns. Est. arrival: Nov 22–Dec 2

Best Price Guarantee

  • Lowest Price Online, Guaranteed. If you find the same product for less at another authorized dealer, we’ll match or beat it.
  • Easy to Claim: click here to submit your price match request
  • Qualifications: Item must be identical, in stock, new (not refurbished/open-box), and sold by an authorized dealer. Total cost (including shipping & tax) must be lower.
  • Peace of Mind: All details you provide are kept completely confidential. We use this information only to verify the price.

Installation

Need installation support? We’ll help you find a qualified pro.

Click here to submit a request.

Request a Quote

Need a price or shipping estimate? Click here to request a quote.

Request a Quote

Price Match Request

Loading...

Installation Support Request

EcoSmart Fire ESF.2.B.AB3 Video

Description

A Round Flame for Bowls, Tables and Custom Features

The EcoSmart Fire AB Series is a round, stainless steel ethanol burner made to sit inside a fire bowl, table, planter or sculpture you design. It burns bioethanol, so it needs no gas line, no wiring and no flue. It gives a single centered flame, the shape you want in anything round or square. It comes in two sizes and two finishes.

Two Sizes: a Tabletop Accent or a Full Fire Pit Flame

The AB3 is the small one, about 10 inches across, sized for a tabletop bowl or a narrow niche, and it warms a small room. The AB8, about 14 inches across, makes a fuller, taller flame and puts out several times the heat, enough for a fire pit centerpiece or a larger room. EcoSmart rates both at roughly 7 to 11 hours per fill, so the choice comes down to the setting and the size of the flame, not how long it runs.

Steel Wool Inside Keeps the Flame Steady

The fuel chamber is packed with steel wool, which holds the ethanol and helps it burn evenly instead of sloshing. In practice that means a calmer flame and steadier fuel use, which matters most in a bowl or table where people sit close to it.

Choose Indoor or Outdoor When You Order

Each AB burner is assembled for one setting. The outdoor version is pre-assembled for outdoor use only, and the indoor version needs different parts, so the one you order is the only place it can be used. Add the setting you need, indoor or outdoor, to the order notes at checkout.

Best for Designers Building Round or Square Features

The AB is the burner behind custom fire bowls, fountains with fire and tabletop features. Many of EcoSmart's own fire pit kits and grates are built around it. If you would rather buy the finished piece, the EcoSmart Fire Round 20 and Square 22 fire pit kits come with an AB8 already fitted. For a linear flame in a wall or fireplace, see the XL Series.

Set It in Non-Combustible Material and Leave Room Above

The AB must sit level in steel, concrete, brick or natural stone, never directly in wood or a laminate top. In a firebox, EcoSmart asks for at least 15.7 inches wide, 13.8 deep and 19.7 tall around the AB3, and 25.6 wide, 17.7 deep and 31.5 tall around the AB8. In an open setting, keep 59.1 inches clear above it indoors, 78.7 inches outdoors, and 23.6 inches from anything combustible. Where people sit close, EcoSmart lists the Plasma Fire Screen for both AB sizes: a clear glass panel on stainless feet that stands in front of the flame.

Fuel is sold separately. Fill only when the burner is cold, and light it with the included rod. Lead time differs by size and finish, so check the note above the cart.

Optional Accessories

EcoSmart Fire Plasma Fire Screen, e-NRG Bioethanol Fuel, EcoSmart Fire Black Glass Charcoal and Twin Feet Fixings.

Features

  • Steel wool fuel chamber for a steady flame and even fuel use
  • Adjustable flame with a closing lid to put it out
  • No gas line, electrical connection or chimney needed
  • Extendable lighting rod and refillable butane lighter included
  • Jerry can spout extension included with the AB3 for its smaller fill opening
  • Burns e-NRG bioethanol, sold separately

Specifications & Manuals

  • Fuel Type
    Ethanol
  • Venting Type
    Ventless
  • Installation
    Indoor, Outdoor, Insert
  • Viewing Configuration
    Single-Sided, See-Through, Open Corner, 3-Sided, Island
  • Width
    10.2"
  • Height
    3.7"
  • Depth
    10.2"
  • Weight
    5.3 lbs
  • BTU Output
    5,800 BTU
  • Heat Coverage
    215 sq. ft. (on average)
  • Ignition Type
    Match Lit
  • Material
    Metal, Stainless Steel
  • Color
    Silver, Black
  • Average Burn Time
    7-11 hours per refill, varies by size
  • Certifications
    UL Listed, ISO Certified
  • Warranty
    2-Year Manufacturer's Warranty
  • Manuals

What's In The Box

  • Ethanol Burner - 1 pc.
  • Lighter - 1 pc.
  • Lighting Rod - 1 pc.
  • Jerry Can (1.25 Gal) - 1 pc.
  • Bottle Adaptor - 1 pc.
  • Jerry Can Spout Extension (AB3 Burner Only) - 1 pc.
  • User's Manual - 1 pc.

EcoSmart Fire AB Series Round Stainless Steel Ethanol Fireplace Burner FAQ's

What is the difference between the AB3 and the AB8?

Size and flame. The AB3 is about 10 inches across for tabletop bowls and small rooms; the AB8 is about 14 inches with a much bigger flame and several times the heat output, for fire pits and larger spaces.

Can I use an AB burner in a fire pit outdoors?

Yes, if you order the outdoor version. EcoSmart assembles each burner for one setting, and the outdoor build can only be used outside.

Can I put the burner in a wooden table?

Not directly. It has to sit in non-combustible material such as steel, concrete or stone, with 23.6 inches to anything combustible around it in an open setting. A steel insert within a table can work if it meets those clearances.

How long does an AB burner burn on one fill?

About 8 to 11 hours for the AB3 and 7 to 11 for the AB8, per EcoSmart, depending on how far the flame is opened.

Do I need a fire screen?

It is not required, but EcoSmart lists the Plasma Fire Screen for the AB3 and AB8, and it is worth having wherever people sit within arm's reach of the flame, especially with children or pets around. It is one flat panel, so it guards the side it stands on.

AB Series or XL Series: which should I choose?

Choose the AB for anything round or square where the flame sits in the middle, like a bowl or table. Choose the XL for a long, linear flame in a wall, fireplace or bar top.
