EcoSmart Fire | Ethanol Burner | ESF.2.B.XL5

EcoSmart Fire XL Series Stainless Steel Ethanol Fireplace Burner

Regular price $2,895.00

A linear ethanol burner for building your own fireplace. Drop it into a non-combustible opening and get a long, real flame with no gas line or chimney.

Need a different shape? See every EcoSmart ethanol burner.

Call to Order

Call or text 1-866-713-2399 to get the best deal!

Free delivery to contiguous U.S. + free 30-day returns. Est. arrival: Nov 22–Dec 2

Best Price Guarantee

  • Lowest Price Online, Guaranteed. If you find the same product for less at another authorized dealer, we’ll match or beat it.
  • Easy to Claim: click here to submit your price match request
  • Qualifications: Item must be identical, in stock, new (not refurbished/open-box), and sold by an authorized dealer. Total cost (including shipping & tax) must be lower.
  • Peace of Mind: All details you provide are kept completely confidential. We use this information only to verify the price.

Installation

Need installation support? We’ll help you find a qualified pro.

Click here to submit a request.

Request a Quote

Need a price or shipping estimate? Click here to request a quote.

Request a Quote

Price Match Request

Loading...

Installation Support Request

EcoSmart Fire ESF.2.B.XL5 Video

Description

Build a Real-Flame Fireplace Without Gas or a Chimney

The EcoSmart Fire XL Series is a linear, stainless steel ethanol burner: the part that makes the flame, designed to sit inside a fireplace or fire feature you build around it. It runs on bioethanol, so there is no gas line, no electrical hookup and no flue to plan for. Think of it as the engine of a custom fireplace. You design the surround, and the XL supplies a long, steady row of real flame. It comes in four lengths and two finishes, for homes, restaurants and hotels.

Four Lengths, From a Compact Insert to a Wide Wall of Flame

The size names follow the burner's metric length: the XL500 is the short one, the XL1200 the longest. Each length needs a matching opening. Built into a firebox, EcoSmart asks for a space at least 31.5, 39.4, 47.2 or 59.1 inches wide for the XL500, XL700, XL900 and XL1200, at least 13.8 inches deep and 19.7 inches tall. Pick the size from the opening you have or plan to build, not the other way around.

A full tank runs roughly 8 to 14 hours depending on the size and how far the flame is opened, so one fill covers an evening and then some. The sliding lid that sets the flame height is also how you put it out.

Real Warmth, but It Is a Decorative Fire

The XL Series puts out real heat, and EcoSmart rates the larger sizes to warm several hundred square feet on average. It is still listed as a decorative appliance, not a furnace: treat it as warmth you can feel across a room, not the heat source for the house. The longer the burner, the bigger the room it needs, because an unvented flame needs fresh air. EcoSmart publishes a minimum room size for each model, so check it before choosing the XL1200 for a small den.

Choose Indoor or Outdoor When You Order

Every XL burner is built for one setting. The outdoor version arrives pre-assembled for outdoor use only, and the indoor version uses different parts, so the one you order is the only place it can be used. Add the setting you need, indoor or outdoor, to the order notes at checkout. If a project might move outside later, plan for that now.

Best for Designers, Builders and Masonry Conversions

This is the burner for someone building the fireplace, not buying one finished. Architects and designers use it in custom surrounds, room dividers and bar tops, and homeowners use it to bring a cold masonry fireplace back to life without running gas. If you would rather start from a ready-made box, the EcoSmart Fire Flex fireboxes come with an XL burner already sized to them. For a round flame in a bowl or table, look at the AB Series round burners.

Plan the Setting Before You Cut the Opening

The burner must sit level, in non-combustible material only: steel, concrete, brick or natural stone. Without a firebox around it, EcoSmart asks for 59.1 inches of clear space above it indoors, 78.7 inches outdoors, and 23.6 inches to anything combustible at the sides or back. It has not been tested with glass doors, so do not close it in with them; a freestanding screen needs a 1.6-inch gap under the glass so the burner can breathe. In a masonry fireplace, adjust the damper so the heat stays in the room. Check the burner's real dimensions against your cut-out before the opening is finished.

The XL ships without fuel. Use e-NRG bioethanol, fill only when the burner is cold, and light it with the included rod. Lead time differs by size and finish, so check the note above the cart for the one you choose.

Optional Accessories

e-NRG Bioethanol Fuel, EcoSmart Fire Black Glass Charcoal, EcoSmart Fire Plasma Fire Screen and Twin Feet Fixings.

Features

  • Sliding lid adjusts the flame height and closes to put the flame out
  • No gas line, electrical connection or chimney needed
  • Fuel tank with visible fill markings, filled from the included jerry can and bottle adaptor
  • Extendable lighting rod and refillable butane lighter included for lighting at arm's length
  • One burner per opening; sizes run from compact to a wide linear flame
  • Burns e-NRG bioethanol, sold separately

Specifications & Manuals

  • Fuel Type
    Ethanol
  • Venting Type
    Ventless
  • Installation
    Indoor, Outdoor, Insert
  • Viewing Configuration
    Single-Sided, See-Through, Open Corner, 3-Sided, Island
  • Style
    Linear
  • Width
    19.7"
  • Height
    4.4"
  • Depth
    7.7"
  • Weight
    14.7 lbs
  • BTU Output
    11,430 BTU
  • Heat Coverage
    431 sq. ft. (on average)
  • Ignition Type
    Match Lit
  • Material
    Metal, Stainless Steel
  • Color
    Silver, Black
  • Average Burn Time
    8-14 hours per refill, varies by size
  • Certifications
    UL Listed, ISO Certified
  • Warranty
    2-Year Manufacturer's Warranty
  • Manuals

What's In The Box

  • Ethanol Burner - 1 pc.
  • Fire Lighter - 1 pc.
  • Lighting Rod - 1 pc.
  • 1.25 Gal Jerry Can - 1 pc.
  • Bottle Adaptor - 1 pc.
  • Butane - 1 pc.
  • XL Baffles - 1 pc.
  • User's Manual - 1 pc.

EcoSmart Fire XL Series Stainless Steel Ethanol Fireplace Burner FAQ's

Can the EcoSmart XL burner be used outdoors?

Yes, if you order the outdoor version. Each burner is assembled for one setting, and EcoSmart says the outdoor build can only be used outdoors, so add the setting you need to the order notes at checkout.

What size opening does each XL burner need?

In a firebox, at least 31.5 inches wide for the XL500, 39.4 for the XL700, 47.2 for the XL900 and 59.1 for the XL1200, with 13.8 inches of depth and 19.7 inches of height. Without a firebox, keep 59.1 inches clear above it indoors and 23.6 inches from combustibles.

How long does a tank of ethanol last?

EcoSmart rates a full tank at about 8 to 14 hours, depending on the size and how far the lid is open. A lower flame burns longer.

Can I put the XL burner in my existing wood-burning fireplace?

Yes, as long as the fireplace is masonry or another non-combustible material and the opening meets the minimum size for your burner. Adjust the damper so heat is not lost up the flue, and do not add glass doors, which the burner has not been tested with.

Does an ethanol burner give off real heat?

It does, and EcoSmart rates the bigger sizes to warm a few hundred square feet on average. It is a decorative appliance, though, so plan on it as extra warmth rather than your main heat.

What is the difference between the XL Series and a Flex firebox?

The XL is the burner on its own, for a surround you build. A Flex firebox is a finished steel box with an XL burner already matched to it, so there is less to design and build.
