EcoSmart Fire | Ethanol Firebox | ESF.FX.50LC.BXL
ESF.FX.50LC.BXL

EcoSmart Fire Flex Left or Right Corner Built-In Ethanol Firebox with Decorative Box

Regular price $7,495.00

A corner ethanol firebox with a glass display box beside the flame. Part of the opening holds fire and part holds stones or steel logs, so a long corner wall gets one continuous window.

Need a different configuration? See every EcoSmart Flex firebox.

Call to Order

Call or text 1-866-713-2399 to get the best deal!

Made to order with FREE U.S. delivery + this item cannot be returned. Est. manufacturing time: 8-10 Weeks

Best Price Guarantee

  • Lowest Price Online, Guaranteed. If you find the same product for less at another authorized dealer, we’ll match or beat it.
  • Easy to Claim: click here to submit your price match request
  • Qualifications: Item must be identical, in stock, new (not refurbished/open-box), and sold by an authorized dealer. Total cost (including shipping & tax) must be lower.
  • Peace of Mind: All details you provide are kept completely confidential. We use this information only to verify the price.

Installation

Need installation support? We’ll help you find a qualified pro.

Click here to submit a request.

Request a Quote

Need a price or shipping estimate? Click here to request a quote.

Request a Quote

Price Match Request

Loading...

Installation Support Request

EcoSmart Fire ESF.FX.50LC.BXL Video

Description

A Corner Firebox That Puts a Display Box Beside the Fire

This EcoSmart Fire Flex corner firebox shares one long glass opening between a real flame and a decorative box, so part of the window shows fire and part shows the stones, glass or steel pieces you place there. The glass runs across the front and around one end, and you choose the box position and the corner side separately. It builds in like a fireplace and burns bioethanol with no gas line, wiring or chimney, indoors or outdoors under a roof.

A Box Shortens the Burner, So It Is a Look, Not More Heat

At any given width, the box takes room that would otherwise hold burner, so a box model runs a shorter burner than an all-flame firebox of the same size. With one box, the 50 runs an XL500 at 11,430 BTU; with two boxes, the 104 runs a single XL1200 at 15,290 BTU. Across the range the output runs from 11,430 to 45,000 BTU, and EcoSmart rates the warmth at about 431 to 1,938 square feet on average. Choose a box for the proportions of the opening, and check the BTU of the exact size and box option in the specs.

Box Left, Right or Both, Chosen Apart From the Corner Side

The box can sit at the left end, the right end, or both ends with the flame in the middle; two boxes are offered on the larger sizes, and the size menu shows which. The corner side is a separate choice, so you can put the flame at the open glass end, where it shows from the side as well as the front, or put the display there and keep the fire toward the wall. Decide that while planning the room, because it sets what people see as they walk in.

Fill the Box Only With Non-Combustible Pieces

EcoSmart's manual says the decorative boxes must hold non-combustible materials only: stone, glass charcoal, ceramic or steel, never firewood, books or plants. Each box has an internal glass panel between it and the flame, and an infill plate that lifts whatever you place there level with the bottom of the opening. The black glass charcoal in the carton is for the burner tray, not the boxes, so plan on extra charcoal or stones to fill them. EcoSmart also offers decorative steel logs for the boxes; they must never sit over the flame.

Best for Long Corner Walls You Want Dressed, Not Just Lit

This is the version for a wide wall where a flame end to end would be more fire than the room needs, or where a designer wants an object or texture beside the fire, such as a dining room, a hotel suite or a living room with a long built-in. If you want the whole opening to be flame, choose the all-flame Flex corner firebox instead, which also comes in smaller sizes.

Frame a Deep Chase and Keep the Open Side Square

The firebox is 14.4 inches deep, so it goes into a chase or bump-out rather than a standard stud wall; studs can be framed tight to it because it is zero clearance. Leave the red brackets on the open end until the framing is done. A 6-inch strip of non-combustible board goes above both open sides, with a metal trim bead on every edge. Outdoors, put it under a roof or overhang so rain cannot fill the firebox. Fuel with e-NRG bioethanol only, and let the burner cool for 60 minutes after shutting it off before refilling. It is made to order, and the lead time is shown above the cart.

Optional Accessories

Metal Log Set for Flex Firebox (copper or brass steel logs for the boxes), e-NRG Bioethanol Fuel and EcoSmart Fire Black Glass Charcoal (to fill the decorative boxes).

Features

  • Decorative box shares the front and side glass with the flame for one long opening
  • Box on the left, right or both ends, chosen separately from the corner side
  • Infill plate lifts display pieces level with the bottom of the opening
  • Internal glass panel separates each box from the fire
  • Sliding lid adjusts the flame and closes it off

Specifications & Manuals

What's In The Box

  • Flex Corner Firebox with Decorative Box(es) and Integrated Glass Windscreen - 1 pc.
  • Decorative Box Internal Glass Panel - 1 per box
  • Decorative Box Infill Plate - 1 per box
  • XL Series Ethanol Burner (one to three, by size and box option)
  • XL Baffles - 1 set per burner
  • Black Glass Charcoal for the burner tray - 1 set
  • Jerry Can 5L with Safety Spout - 1 pc.
  • Bottle Adaptor - 1 pc.
  • Lighting Rod - 1 pc.
  • Fire Lighter - 1 pc.
  • Red Stability Brackets (installation aid) - 1 set
  • Installation and Operation Manuals

EcoSmart Fire Flex Left or Right Corner Built-In Ethanol Firebox with Decorative Box FAQ's

What can I put in the decorative box?

Only non-combustible pieces, such as stones, black glass charcoal or steel logs. EcoSmart's manual rules out anything that can burn, and the charcoal in the carton is for the burner tray, so plan on extra to fill the box.

Should I choose a Flex corner with a box or without?

With a box if you want a long opening with a display beside the fire; without if you want the most flame and heat for the width. At the same size, the box version runs a shorter burner.

Can I have a box on both sides of a corner firebox?

Yes, on the larger sizes, with the flame in the middle. The size menu shows which widths offer Both Sides.

Is the display box separated from the flame?

Yes. Each box has an internal glass panel between it and the burner, behind the same front and side glass as the fire.

How much heat does the box version give off?

From 11,430 to 45,000 BTU depending on size and box option, which EcoSmart rates to warm about 431 to 1,938 square feet on average.

Which side should the box go on?

Whichever suits the room. Put the flame at the open glass end if you want the fire seen from the side as you walk in, or the box there if the display is the feature.
